EyeCGas® 2.0 Optical Gas Detector for Methane, Hydrocarbons, more than 400 VOCs and CO2

EyeCGas 2.0 is the world’s most sensitive handheld Optical Gas Imaging (OGI) camera. It quickly identifies fugitive gas emissions for over 400 hydrocarbon and VOC gases. Including Methane and CO2. EyeCGas 2.0 is Intrinsically Safe and complies with the EPA’s “Quad Oa” (OOOOa) regulations. EyeCGas 2.0 is used globally across the industry for LDAR compliance. It is certified and Classified for hazardous environments ANSI/ISA-Class I and II, Div. 2, & Class III, CSA C22.2 Class I, Div. 2 and ATEX II, IECEx EMT 19.0006X as Intrinsic Safety “ic”, protection “n”. Clearly designed to work in harsh conditions. Based on customer feedback, EyeCGas 2.0 has a wide range of unique features making it the best OGI camera in the world. EyeCGas 2.0 by Opgal helps you detect and repair gas leaks inside the facility limits without the need of a hot permit, allowing video and audio recording and streaming, while maintain safety.

Better Connectivity – With the best connectivity of any OGI camera in the world, EyeCGas 2.0 offers video streaming and downloading via WiFi, and Bluetooth integration with 3rd party software and devices.
Better Safety – An Intrinsically Safe camera for OGI, EyeCGas 2.0 is designed explicitly for the Oil and Gas industry’s harsh environments. It is certified to meet IEC standards for temperature, humidity, vibration, dust, and IP65 water & dust protection. Certified for use in Class I Div 2 ATEX II hazardous environments.
Higher Sensitivity – With NETD of <10mK, EyeCGas 2.0 is the most sensitive OGI camera. It can detect leaks as small as 0.35 g/hr (methane) and is fully certified to meet EPA (NSPS) 40 CFR part 60, subpart OOOOa requirements.
Better Usability – EyeCGas 2.0 has smart LDAR operations offering wireless integration with leading LDAR software and quantification devices, allowing real-time component tag synchronization and a simple association between components, images, and videos.
More Versatile – Thermography mode enables accurate temperature measurement, six color palettes, and an option for easy export of radiometric data.
Multi-Spectral Filters – EyeCGas 2.0 is the only OGI camera that offers three operator replaceable filters; for VOC gases 3.2μm to 3.4μm, for heavier alkanes (better for long-range detection) 3.3μm to 3.5μm and for CO2 4.2μm to 4.4μm.

ANSI/ISA-12.12.01-Nonincendive Electrical Equipment for Use in Class I and II, Division 2, and Class III Hazardous (Classified) Locations,
CSA C22.2 No. 213-M1987, First Edition: Non-Incendive Electrical Equipment for Use in Class I, Division 2 Hazardous Locations.
IECEx EMT 19.0006X as Intrinsic Safety “ic”, protection “n”
EMT19ATEX0009X
Ex II 3 GD
Ex ic nA nC IIC T6 Gc Tamb = -20 °C to +50 °C
Ex ic IIIC T85 °C Dc Tamb = -20 °C to +50 °C

EyeCGas 2.0 is backed by a 4-year warranty. With thousands of customers internationally from producers, service providers and governmental regulators. EyeCGas 2.0 allows for reliable, safe, quick, and cost effective detection for all industry requirements. Avoid unnecessary shut down, ensure employee safety, and stay on top of regulatory compliance. For more information or a quote, contact us today.

Accessories

Technial Specifications

IMAGING PERFORMANCE - THERMAL IMAGER

THERMAL SENSITIVITY: <10mK@ 25˚C
OPTICS: f/1.1; 18° with 30mm lens; Manual focus
DIGITAL ZOOM: x2, x4, x8 and x16 (only for visible camera)

DIGITAL VIDEO CAMERA

EMBEDDED DIGITAL CAMERA: HD, fixed focus, for situational awareness

DETECTOR

TYPE: Cooled High Sensitivity, 320 x 240 pixels
SPECTRAL RANGE: 3 to 4.4µm

POWER INPUT

POWER: 12 VDC: 13W
BATTERY LIFE: >4.5 hours continuous operation

PHYSICAL CHARACTERISTICS

WEIGHT (WITH BATTERY AND LENS): 2.6kg (5.9 lbs)
COLOR: Grey and Black
SIZE IN (LXHXW): 9″ x 4.3″ x 5.1″ (230 x 110 x 130) mm
INTERFACE: Tripod mounting UNC 1/4″, rotation safe

THERMOGRAPHY

MEASUREMENT: Spot temperature measurement
RANGE: -20°C to +350 °C
ACCURACY: At Least ± 1 °C (0 – 100 °C), ± 2% (> 100 °C), ± 2°C (-20 – 0 °C)
COLOR PALETTES: 6 color palettes (Rainbow, Iron, ISO red, ISO green, Grey Scale and Vivid)

QUANTIFICATION

GAS QUANTIFICATION: Image processing VOC gas quantification for desktop or handheld application (offline/online operation)

DISPLAY

DISPLAY UNIT: 3.5” Color LCD 640X480

ENVIRONMENTAL CONDITIONS

OPERATING TEMPERATURE RANGE: -20°C to + 50°C
STORAGE TEMPERATURE RANGE: -40°C to + 70°C
TEMPERATURE AND HUMIDITY: IEC 60068-2-30 Temp. +25°C / +40°C Humidity 95% RH
EMC/ EMI: EN 60079-0:2012/A11:2013, EN 60079-11:2012, EN 60079-15:2010, IEC 60079-0:2017, IEC 60079-11:2011,IEC 60079-15:2010, IEC 60079-31:2013
VIBRATION: 2.4 GRMS Random Vibration
WATER AND DUST PROTECTION: IP65
HALT – HIGH ACCELERATED LIFE TEST: Max temp: 55°C, Min temp: -20°C
SAFETY: EN60950-1:2006
HAZARDOUS LOCATIONS SAFE: CSA C22.2 No. 213-M1987, Non-Incentive Electrical Equipment for Use in Class I, Division 2, ANSI/ISA-12.12.01 – Class I and II, Division 2, and Class III, ATEX.
Intrinsically safe for Zone 2 ratings as: Ex II 3 GD; Ex ic nA nC IIC T6 Gc; Ex ic tc IIIC T85°C DC

Environmental Conditions when Packed in Carrying Case

FREE FALL (DROP) TEST: ASTM-D 4169-06 Schedule A
LOOSE CARGO VIBRATION TEST: ASTM-D 4169-08 Schedule F Test method D999
VIBRATION: ASTM-D 4169-08 Schedule F Test method D999

GAS LEAK DETECTION PERFORMANCE

OPERATION FEATURES: Auto and Enhanced Modes
WITH SPECTRAL FILTER OF 3.2µM TO 3.4µM FOR VOCs GASES DETECTION: 400+ compounds such as: Methane, Acetic acid, Benzene, Butadiene, Butene, Butane, Dimethyl-Benzene, Ethane, Ethylene, Ethyl benzene, Ethylene oxide, Hexane, Heptane, Isobutylene, Isopropyl alcohol, Isoprene, Methanol, MEK Methyl Ethyl Ketone, Octane, Pentene, Propane, Propanal

DIGITAL VIDEO AND AUDIO RECORDING

VIDEO AND AUDIO RECORDING: Digital video recorder build-in generates a .ts format video on all modes.
SNAPSHOT CAPABILITIES: Snapshot command generates a .jpg file on any of the available modes
STORAGE: Up to 20 hours and more of video storage over a 64GB solid state memory

COMMUNICATION INTERFACES

USB: Data transfer, video streaming and video images file transfer
Wi-Fi: 2.4 GHz for video streaming and file transfer
Bluetooth: Bluetooth 4.2 with other devices: RMLD, TVA2020 ,LDAR software etc…
GPS: Built in or external

SUPPLIED ACCESSORIES

Batteries (2), Battery Charger, USB Cable, Neck strap, Glare Shield, Carrying Case, Cleaning Kit.
