EyeCGas^® 24/7 PRO

Detection, Emission Rate Quantification, Source Localization

Product Features

Site Level Continues Emission Monitoring

Bi-channel camera to rule out False Positive alerts

Reduce the influence of environmental conditions

Dedicated Management Software

Cooled Dual Spectrum OGI technology

Pan & Tilt Mounting

Wide Coverage

Real Time Alerts

Application Videos

EyeCGas 24/7 PRO OGI Solutions is an Automated Video Management platform for Industrial Applications

EyeCGas 24/7 PRO OGI Solutions is an industrial video management platform for the Oil & Gas Industry. It combines real-time monitoring and alerts in a single intuitive and modular solution.

EyeCSite Pro is a consolidated Automated Video Management platform for industry; combining thermography, fugitive gas leak detection & quantification, flare monitoring, fire detection, and alerts within one intuitive and modular software.

By taking advantage of a unified approach for industrial monitoring your organization becomes more efficient, makes better decisions, and responds to situations and threats with greater confidence.

Technical Specifications

MWIR Core

Thermal Sensitivity: < 10mK@ 25 ̊C
Pixel Pitch: 30μm
Field of View: 7.4 X 5.44°
Focus: Fixed Focus
Accuracy: +/-1°C (from -10°C to +60°C)
Detector: MCT (3-4.4 μm)
FPA: 320 × 240 pixels
Spectral Range: 3.3 - 3.6 μm

LWIR Core

Thermal Sensitivity: < 50mK@ 25 ̊ C
Pixel Pitch: 17μm
Field of View: 18.5° X 13.6°
Focus: Fixed Focus
Accuracy: +/-1°C (from -10°C to +60°C)
Detector: Microbolometer
FPA: 288 x 384
Spectral Range: 8 – 12 μm

Visible Camera

Resolution: 2065 x 1533 @ 30fps
Frame Rate: 30 fps
Sensor: 1/2.8” Progressive CMOS, 3MP
Optical Filter: Automatic removable IR cut filter for low light
Sensitivity: Color: 0.04 lux, B/W: 0.002 lux

General

Voltage: 12 VDC - 48VDC
Power Consumption: 20W
Operating Temperature: -20°C to +50°C
Storage Temperature: -40°C to +71°C
Pan Angle: 360° (continuous rotation)
Pan Speed: 0 – 40°/second
Pan Torqu:e 20Nm (limited with safety device)
Tilt Angle: 180° (+/-90°)
Tilt Speed: 0 – 20°/second
Tilt Torque: 20Nm (limited with safety device)

Downloads

Opgal 24/7 Fixed OGI Monitoring System

The EyeCGas 24/7 Pro Fixed OGI system, a site level continuous emission monitoring solution. EyeCGas 24/7 Pro is mounted on a motorized pan & tilt mechanism, which provides the ability for wide coverage. It has a dedicated management software, with real time site level alerts and triangulation analysis.

DOWNLOAD

EyeCGas Catalog

Over a decade ago, Opgal introduced to the market its first OGI (Optical Gas Imaging) camera. This groundbreaking OGI camera has revolutionized the way inspections are held in the Oil & Gas industry.

DOWNLOAD

EyeCSite Pro Brochure

A consolidated Automated Video Management platform for industry; combining thermography, fugitive gas leak detection & quantification, flare monitoring, fire detection, and alerts within one intuitive and modular software.

DOWNLOAD

EyeCSite Quantification Software

DOWNLOAD

OGI Academy – Sensitivity

OGI sensitivity is the proven metric for the efficiency of the OGI camera for compound detection. The more sensitive the camera, the smaller the leaks it can detect.

DOWNLOAD

OGI Academy – Long Range OGI Detection

By having the ability to change spectral filters and placing a heavy hydrocarbon filter in the camera, you can improve the ability to VOCs at longer distances.

DOWNLOAD
