EYECGAS^® Multi

Methane, Vocs & Co₂

Product Features

Multi Spectral Filters

EPA 0000'a/b/c Compliant

Built In Quantification

Wireless Connectivity

4-5 Hour Battery Life

4 Year warranty

No Annual Calibration Required

Intrinsically Safe

Thermographic Imaging

Gas Leak Detection

Application Videos

EyeCGas® Multi Optical Gas Detector for Methane, Hydrocarbons, more than 400 VOCs and CO₂ EyeCGas Multi is the world’s most sensitive handheld Optical Gas Imaging (OGI) camera. It quickly identifies fugitive gas emissions of over 400 hydrocarbon and VOC gases. Including Methane and CO₂. EyeCGas Multi is Intrinsically Safe and complies with the EPA’s OOOO’a/b/c regulations. With the widest performance envelope. EyeCGas Multi is used globally across the industry for LDAR compliance. It is certified and Classified for hazardous environments ANSI/ISA-Class I and II, Div. 2, & Class III, CSA C22.2 Class I, Div. 2 and ATEX II, IECEx EMT 19.0006X as Intrinsic Safety “ic”, protection “n”. Clearly designed to work in harsh conditions. Based on customer feedback, EyeCGas Multi has a wide range of unique features making it the best OGI camera in the world. EyeCGas Multi by Opgal helps you detect and repair gas leaks inside the facility limits without the need of a hot permit, allowing video and audio recording and streaming, while maintain safety.

Multi-Spectral Filters – EyeCGas Multi is the only OGI camera that offers three operator replaceable filters; for VOC gases 3.2μm to 3.4μm, for heavier alkanes (better for long-range detection) 3.3μm to 3.5μm and for CO₂ 4.2μm to 4.4μm.
Built In Quantification – Easily Measure concentration as well as mass flow of various VOC emissions in real time using a user friendly interface.
Wireless Connectivity – With the best connectivity of any OGI camera in the world, EyeCGas Multi offers video streaming to the officially EyeCGas App via WiFi, and Bluetooth integration with 3rd party software and devices.
Better Safety – An Intrinsically Safe camera for OGI, EyeCGas Multi is designed explicitly for the Oil and Gas industry’s harsh environments. It is certified to meet IEC standards for temperature, humidity, vibration, dust, and IP65 water & dust protection. Certified for use in Class I Div 2 ATEX II hazardous environments.
Higher Sensitivity – With NETD of <10mK, EyeCGas 2.0 is the most sensitive OGI camera. It can detect leaks as small as 0.35 g/hr (methane) and is fully certified to meet EPA (NSPS) 40 CFR part 60, subpart OOOO’a/b/c requirements.
Better Usability – EyeCGas Multi has smart LDAR operations offering wireless integration with leading LDAR software and quantification devices, allowing real-time component tag synchronization and a simple association between components, images, and videos.
More Versatile – Thermography mode enables accurate temperature measurement, six color palettes, and an option for easy export of radiometric data.
4 year warranty – This ruggedized camera was built to last. Rest assure your investment in guaranteed with the longest warrantee in the market.
Free firmware updates: Receive camera software upgrades and improvements regularly free of charge.

ANSI/ISA-12.12.01-Nonincendive Electrical Equipment for Use in Class I and II, Division 2, and Class III Hazardous (Classified) Locations,
CSA C22.2 No. 213-M1987, First Edition: Non-Incendive Electrical Equipment for Use in Class I, Division 2 Hazardous Locations.
IECEx EMT 19.0006X as Intrinsic Safety “ic”, protection “n”
EMT19ATEX0009X
Ex II 3 GD
Ex ic nA nC IIC T6 Gc Tamb = -20 °C to +50 °C
Ex ic IIIC T85 °C Dc Tamb = -20 °C to +50 °C

EyeCGas Multi is backed by a 4-year warranty. With thousands of customers internationally from producers, service providers and governmental regulators. EyeCGas Multi allows for reliable, safe, quick, and cost effective detection for all industry requirements. Avoid unnecessary shut down, ensure employee safety, and stay on top of regulatory compliance. For more information or a quote, contact us today.

Technical Specifications

IMAGING PERFORMANCE - THERMAL IMAGER

THERMAL SENSITIVITY: <10mK@ 25˚C
OPTICS: f/1.1; 18° with 30mm lens; Manual focus
DIGITAL ZOOM: x2, x4, x8 and x16 (only for visible camera)

Gas Sensitivity

NECL @ delta T =10C:
Methane- 9 ppm m
Propane- 2.8 ppm m
Butane- 2.3 ppm m

Minimum Leak Rate @ delta T =10C:
Methane- 0.07 g/h
Propane- 0.05 g/h
Butane- 0.05 g/h

Minimum Laboratory Leak Rate:
Methane- 0.35 g/h
Propane- 0.26 g/h
Butane- 0.29 g/h

DIGITAL VIDEO CAMERA

EMBEDDED DIGITAL CAMERA: HD, fixed focus, for situational awareness

Detector and Optical Data

DETECTOR TYPE: Focal plane array (FPA), cooled MCT
DETECTOR SPECTRAL RANGE: 3.1 μm to 4.4 μm
OPTICAL FILTERS: Std. 3.2-3.5 μm; Long range 3.3-3.6 μm; CO2 4.1-4.4 μm
SENSOR COOLING: Stirling Microcooler
DIGITAL IMAGE ENHANCEMENT: High sensitivity mode (HSM), noise reduction filter
AVAILABLE LENSES: 18° (30 mm); 7.5° (75 mm)
F-NUMBER: 1.1

POWER INPUT

POWER: 12 VDC: 13W
BATTERY LIFE: >4.5 hours continuous operation

PHYSICAL CHARACTERISTICS

WEIGHT (WITH BATTERY AND LENS): 2.6kg (5.9 lbs)
COLOR: Grey and Black
SIZE IN (LXHXW): 9″ x 4.3″ x 5.1″ (230 x 110 x 130) mm
INTERFACE: Tripod mounting UNC 1/4″, rotation safe

THERMOGRAPHY

MEASUREMENT: Spot temperature measurement
RANGE: -20°C to +350 °C
ACCURACY: At Least ± 1 °C (0 – 100 °C), ± 2% (> 100 °C), ± 2°C (-20 – 0 °C)
COLOR PALETTES: 6 color palettes (Rainbow, Iron, ISO red, ISO green, Grey Scale and Vivid)

QUANTIFICATION

GAS QUANTIFICATION: Image processing VOC gas quantification for desktop or handheld application (offline/online operation)

DISPLAY

DISPLAY UNIT: 3.5” Color LCD 640X480

ENVIRONMENTAL CONDITIONS

OPERATING TEMPERATURE RANGE: -20°C to + 50°C
STORAGE TEMPERATURE RANGE: -40°C to + 70°C
TEMPERATURE AND HUMIDITY: IEC 60068-2-30 Temp. +25°C / +40°C Humidity 95% RH
EMC/ EMI: EN 60079-0:2012/A11:2013, EN 60079-11:2012, EN 60079-15:2010, IEC 60079-0:2017, IEC 60079-11:2011,IEC 60079-15:2010, IEC 60079-31:2013
VIBRATION: 2.4 GRMS Random Vibration
WATER AND DUST PROTECTION: IP65
HALT – HIGH ACCELERATED LIFE TEST: Max temp: 55°C, Min temp: -20°C
SAFETY: EN60950-1:2006
HAZARDOUS LOCATIONS SAFE: CSA C22.2 No. 213-M1987, Non-Incentive Electrical Equipment for Use in Class I, Division 2, ANSI/ISA-12.12.01 – Class I and II, Division 2, and Class III, ATEX.
Intrinsically safe for Zone 2 ratings as: Ex II 3 GD; Ex ic nA nC IIC T6 Gc; Ex ic tc IIIC T85°C DC

Environmental Conditions when Packed in Carrying Case

FREE FALL (DROP) TEST: ASTM-D 4169-06 Schedule A
LOOSE CARGO VIBRATION TEST: ASTM-D 4169-08 Schedule F Test method D999
VIBRATION: ASTM-D 4169-08 Schedule F Test method D999

GAS LEAK DETECTION PERFORMANCE

OPERATION FEATURES: Auto and Enhanced Modes
WITH SPECTRAL FILTER OF 3.2µM TO 3.4µM FOR VOCs GASES DETECTION: 400+ compounds such as: Methane, Acetic acid, Benzene, Butadiene, Butene, Butane, Dimethyl-Benzene, Ethane, Ethylene, Ethyl benzene, Ethylene oxide, Hexane, Heptane, Isobutylene, Isopropyl alcohol, Isoprene, Methanol, MEK Methyl Ethyl Ketone, Octane, Pentene, Propane, Propanal

DIGITAL VIDEO AND AUDIO RECORDING

VIDEO AND AUDIO RECORDING: Digital video recorder build-in generates a .ts format video on all modes.
SNAPSHOT CAPABILITIES: Snapshot command generates a .jpg file on any of the available modes
STORAGE: Up to 20 hours and more of video storage over a 64GB solid state memory

COMMUNICATION INTERFACES

USB: Data transfer, video streaming and video images file transfer
Wi-Fi: 2.4 GHz for video streaming and file transfer
Bluetooth: Bluetooth 4.2 with other devices: RMLD, TVA2020 ,LDAR software etc…
GPS: Built in or external

SUPPLIED ACCESSORIES

Batteries (2), Battery Charger, USB Cable, Neck strap, Glare Shield, Carrying Case, Cleaning Kit.

* Batteries – 1 year warranty
** IR Detector & Cooler – 2 years warranty
