EYECGAS^® MINI

Product Features

Cost Effective

Thermography and Visible Overlay

Multiple Models

Automatic Gas Detection

Connectivity

Built-in GPS

User Friendly Interface

Multiple IR Palettes & Image Modes

Application Videos

EyeCGas Mini Uncooled Thermal Camera for Optical Gas Imaging (OGI)

EyeCGas^® Mini is a compact, handheld and user-friendly uncooled OGI camera for gas leak detection. The Mini comes in multiple models, which, using different kind of filters, can detect Methane, SF6, Ammonia, HFC Refrigerants and more. Feature-rich, this small handheld camera allows wireless communication, data streaming, image fusion, thermography, video & audio recordings, and more. Compact and durable, the EyeCGas Mini revolutionizes the way inspections are held.

Technial Specifications

Image Presentation and Framerate

Image Frequency: 9 Hz IR, 30Hz Visible
Display: OLED, 6 Inch, 1080×2160 pixels, 16 M Colors, Touch-screen
Visible Digital Camera: 12MP
IR Color Palettes: Hot White / Hot Black / Iron / Rainbow / Grey / Vivid
Image Mode: Fusion
Video: Streaming TBA
Image Format: BMP, AVI

Image and Optical Data

Sensor Resolution: 384 x 288
Focal Plane Array: Uncooled Microbolometer
Spectral Range: 7.5 – 9 µm
Detector Pitch: 17µ
Thermal Sensitivity: <50mK @ 25 °C
Gas Sensitivity: >10 gr/hr (Methane)
Field of View: 19° x 14° Manual Focus
Focal Length: 20mm
F#: 1.0
Digital Zoom: Included

General

Thermography: 10 - 85 °C
Accuracy: ± 3°C
Data Stotage: 128 GB
Interface: Bluetooth, Wi-Fi
GPS: Included
Size (mm): 180 x 80 x 60
Weight: 600 gr
Operating Time: > 5 hours
Charging: Standard USB C port
